Transmits HDMI video and audio signals up to 50M over a single CAT6 cable;
Support video resolution up to 3840*2160@60Hz signal;
Supports screen formats YUV444 and RGB444;
Compliance with HDMI 2.0 and HDCP 2.2 standard;
Standard Ethernet IEEE-568B connection for easy installation；
High compatibility, can auto-match source and display device;
Built-in automatic adjustment system, make the image smooth, clear and stable;
Simple to install, plug and play
Package list
HDMI transmitter ………………… 1 pcs
HDMI receiver …………………… 1 pcs
Power adapter …………………… 2 pcs
User manual ……………………… 1 pcs
Specifications
Parameter | Description |
Video | Standards | HDMI 2.0; HDCP 2.2 |
Maximum pixel clock | 340MHz | |
Maximum data rate | 18Gbps | |
Maximum resolution | 3840*2160@60Hz | |
Connector | HDMI-A | |
Impedance | 100Ω | |
UTP | Interface | RJ45 |
Transmission distance | CAT6 - up to 50M at 4K@60， | |
Other | Power supply | The power adapter: DC 5V |
Power dissipation | MAX 3W | |
Temperature | Operating: -5℃ ~ +70℃ | |
Humidity | Operating: 5% ~ 90% | |
Dimension | 81*45*23mm | |
The warranty | 1 year free warranty |
Panel
Port name | Description |
DC 5V | DC 5V/1A power input |
HD IN/HD OUT | HDMI signal input/output |
UTP | RJ45 port connect cat6 |
LED indicator | Description |
STA | HDMI signal status indicator, HDMI signal is normal , the light is always on |
PWR | Power indicator, after the power is turned on, the light is always on |
Installation
1、 The HDMI signal source (such as set-top boxes, Blu ray DVD, computers, etc.) access to the HDMI transmitter ;
2、 Connect the receiver of the HDMI extender to the display device (such as a high definition TV, a tiled screen, etc.);
3、 Use the network cable (recommended 6 types of cable) to connect the sender and receiver network interface;
4、 Will be the transmitter or the receiver connected to a power source, when the indicator lights up normally, normal operation of system.
Warranty
Please keep the user manual in a place where safety and easy to find so that you can read it immediately when meet problems.
safety instruction:
l Please do not disassemble this product by yourself because it doesn't including DIY function.
l Please don't make the product touch water in case damaged, because it is Not waterproof design.
l Please use dry cloth material when clean the product surface.
l Please do not use this product in the environment of too wet or too high temperature.
l Please avoid contact with corrosive substances.
l When there is damage or other physical damage to the product, please stop using and contact with customer service to get support.
